Rebaydo Amplifier 12V 144W 3 Channel 4 Amp Common Anode

Rebaydo 1pc RGB LED Amplifier Repeater 12V 3 Channel 4A is a compact RGB signal booster designed to repeat and synchronize RGB LED control signals over long distances, ensuring stable and consistent color output across extended LED strip, tube, or module installations, and enabling unlimited system expansion by linking multiple amplifiers together, supporting DC 5V, 12V, and 24V optional input voltage with 3-channel output and output current of less than 4A per channel, delivering up to 60W at 5V, 144W at 12V, and 288W at 24V, featuring low static power consumption under 1W and operating within a temperature range of -20°C to 60°C, compatible with both common anode and common cathode RGB systems, constructed with a durable anodized brushed aluminum housing for efficient heat dissipation and long-term stability, with external dimensions of approximately L105 x W65 x H25mm (0.98 x 3.09 x 2.56 inches), and includes a user manual for installation and configuration.
