Midget Screw Round 6 12 24 VDC T 1-3/4 Dim-able 90 Degree E5
Actual Product may vary from picture shown.
One product per package unless otherwise stated.
Click to Enlarge Image View Larger Photo

Midget Screw Round 6 12 24 VDC T 1-3/4 Dim-able 90 Degree E5

Product Code: 24577

Price : $1.37 - $1.49
spacer   Volume Price Information   spacer
 Buy 2 or more and pay $1.46 each (save 2.00%)
 Buy 4 or more and pay $1.45 each (save 3.00%)
 Buy 6 or more and pay $1.43 each (save 4.00%)
 Buy 8 or more and pay $1.42 each (save 5.00%)
 Buy 10 or more and pay $1.40 each (save 6.00%)
 Buy 25 or more and pay $1.39 each (save 7.00%)
 Buy 100 or more and pay $1.37 each (save 8.00%)
Qty:Add To Cart
Add To Saved Cart
Watch the Video
Warranty: 12 Months

Small E5 Midget 1 L.E.D., Available in 6VDC, 12VDC and 24VDC options. Up to 7 Lumen output, long life up to 50,000 hours. Available in Warm White 3000K and White 6000K. Uses very low .1 W power, uses 20ma@6V, 13ma@12v. The viewing angle is 90 degrees. MINIATURE T1 3/4 MIDGET SCREW (E5) BASE BULB. Comparable to a 4 Watt incandescent bulb. CRI>75. The led lamp is called E5 since the base is 5 mm in diameter. This bulb is real small for E5 female screw base socket or lamp holder. The bulb operates at 6 Volt, 12 Volt and 24 Volts. This led bulb works great for back lighting for the ignition switch and various other areas of the dashboard compatible with Rolls Royce cars. This bulb is compatible with #272-1143, 272-1143, #8362, #335, #373, #342, #399, #1768, #1775, 176769L, #7326, #1769 These are tiny led light bulbs. The lamp will turn on around 2.5 Volts and gets brighter up to 6 Volts. Where should you buy or purchase tiny led bulbs? From LEDLight.com. For 6 Volt the bulb can handle up to 9 Volts. For 12 Volt the bulb can handle up to 17 Volts. For 24 Volt the bulb can handle 32 Volts. The 24 Volt bulb starts to illuminate at 5 volts.
