#63 Miniature Bulb BA15S Base 6 Volt 15 SMD 3030
Actual Product may vary from picture shown.
One product per package unless otherwise stated.

#63 Miniature Bulb BA15S Base 6 Volt 15 SMD 3030

Product Code: 84765

Price : $3.58 - $3.89
spacer   Volume Price Information   spacer
 Buy 2 or more and pay $3.81 each (save 2.00%)
 Buy 4 or more and pay $3.77 each (save 3.00%)
 Buy 6 or more and pay $3.73 each (save 4.00%)
 Buy 8 or more and pay $3.70 each (save 5.00%)
 Buy 10 or more and pay $3.66 each (save 6.00%)
 Buy 25 or more and pay $3.62 each (save 7.00%)
 Buy 100 or more and pay $3.58 each (save 8.00%)
Qty:Add To Cart
Add To Saved Cart
Warranty: 12 Months

Works in positive or negative ground vehicles. Single filament lamp. Operates 6 volts non polarity. Super bright led lamp using the latest high power 3030 SMD led. Each 3030 SMD can emit up to 30 Lumen output. Up to 400 Lumen output. Up to 31 CP candle power. Super low profile to fit in the those small cowl lights, indicator, taillight. Viewing angle is 120 degrees. Comparable to a 25 to 30 watt halogen light bulb. Available in White 6000K, Warm White 3000K, Red 625 nm and Yellow Yellow 594 nm. Extremely long life up to 30,000 hours. Solid state never have to worry about a broken filament with led lamps. Compatible with early vintage cars, trucks and motorcycles. Dimmable with a variable voltage supply such as your dashboard dimmer. Single Contact Bayonet where the bayonets are parallel to each other with one contact at the bottom. Compatible with the C6 Filament shape. The maximum overall length M.O.L. is .888 inches. The maximum bulb diameter is .748 inches. The base is 15mm with a single contact BA15S base.. Compatible with Ford Model T Ford Model A Buick #63 Mazda bulb 63 #87 mini6 Volt Positive or Negative Ground. Single filament C-6 S9. 30 quantity 5730 SMD LED's. Up to 500 Lumen. The LED are optically aligned to the original filament location. Since the leds are aligned they are able to output to the reflector and lens better light output. Comparable to a 25 to 35 Watt incandescent light bulb. The viewing angle is 120 degrees. The lamp is dimmable using a variable voltage source. Since the lights are dim-able they operate better when there is a low voltage condition. The bulbs are available in white 6000K, warm white 3000K, Red 625 nm, Green 526 nm, Blue 464 nm & Yellow 594 nm. The bulbs are non polarity or not polarized so you can use them in sockets that are wired backwards such as RV's and boats. This bulb works great for your vintage or classic vehicle that you want to use led lights. They are easy to install by removing old light bulb and inserting new led light bulb. If you are updating your bulbs that are in the turn signal circuit we recommend using 6 ohm load equalizer for each led in the turn signals. Long life up to 30,000 hours. Long warranty please see bottom of the page for warranty details. The maximum overall length MOL is 1.944 inches. The maximum diameter is .741 inches. The base is BA15S 15mm diameter base with a single contact. Compatible with: 87 #87 #1129 1129 1129 60 led light bulb. 6 Volt positive or negative ground. Very bright up to 900 Lumen output. The bulb is not polarity sensitive so you can use it either positive ground or negative ground chassis. The base is BA15S single contact with bayonets parallel. This bulb is dim-able using a variable voltage supply. The bulb operating life is up to 30,000 hours or longer. The viewing angle is 360 degrees. The leds are optically aligned with your reflector for maximum led light output. The maximum overall length is 1.944 inches. The maximum diameter is 1.058 inches. The base is BA15S 15mm standard base size with a single contact. Comparable to a C-6 single filament. The bulb is dim-able with a variable voltage supply such as your dashboard dimmer. The CP candle power is up to 70 CP. Great for vintage and classic cars, trucks and tractors. The BA15S base is 15mm diameter which is standard is for BA15S base so you know it fits your socket. The bulb is comparable to a 55w - 65w incandescent light bulb. The color options are white 6000k, warm white 3000k, Red 625 nm, Green 526 nm, Blue 464 nm & Yellow 594 nm. CE and Rohs listed. Compatible with: 87 #87 #1129 #1133 1133 1129 BA15S 1962 international harvester 110 truck BA15S 1962 international harvester 110 truckature bulb
